I am doing this project to better understand how physical machines behave and how their signals can be turned into meaningful digital insight. By building a small, on-prem digital twin from real sensors and real data, I can learn how hardware, data pipelines, signal processing, and models fit together as one system. The goal is not a finished product, but practical understanding that transfers to larger industrial problems like monitoring, diagnostics, and predictive maintenance.

Digital Workshop Twin — Project Summary (Current State)

Project Goal

Build a learning-focused digital twin of a personal workshop.

• Purpose: understand physical signals → data pipeline → digital representation

• Focus on observability and system understanding

• Not a production system

• No machine control

• Fully on-prem, LAN-only

Workshop Scope

Machines planned in the twin (3–4 total):

1. Lathe (first instrumented and active)

2. Mill

3. Furnace

4. 3D printer

Phase-1 behavior:

• Show machine state only

  • OFF / IDLE / RUNNING / FAULT / UNKNOWN

• Visual indicators only

• No start/stop or control actions

System Architecture

Server / Backbone

• Dell Precision 3420

• Ubuntu 22.04.5 LTS

• Runs headless, 24/7

• SSH hardened (key-only, no passwords)

• Acts as:

  • MQTT broker

  • Data aggregation point

  • Visualization host

Network

• All devices on the same LAN

• No internet dependency

• MQTT used for all telemetry

Messaging Layer (Locked)

MQTT Broker

• Mosquitto

• IP: 192.168.0.105

• Port: 1883

• Anonymous LAN access

• Verified with CLI and live subscriptions

Topic Structure (v1)

workshop/<machine>/heartbeat

workshop/<machine>/telemetry

(workshop/<machine>/state planned next)

Lathe Hardware (Working Baseline)

Edge Node

• FireBeetle ESP32-S3

• Boots fully headless

• Stable Wi-Fi and MQTT reconnect logic

• Powered from wall USB supply (not machine USB)

Sensor

• LIS2DW12 accelerometer

• I2C @ 100 kHz

• Address: 0x19

• Mounted directly on lathe structure

Sensor Configuration

• High-Performance mode

• ±2 g range

• 100 Hz internal ODR

• Telemetry published at 5 Hz

Data Produced (Verified)

Heartbeat (1 Hz)

Confirms device health and connectivity.

{

  "device": "firebeetle-esp32s3",

  "machine": "lathe",

  "uptime_ms": 186373,

  "rssi": -46

}

Telemetry (5 Hz)

Raw acceleration in physical units.

{

  "device": "firebeetle-esp32s3",

  "machine": "lathe",

  "uptime_ms": 186573,

  "accel_mps2": [-1.42, 9.77, -0.18]

}

End-to-end verified:

• Sensor → ESP32 → Wi-Fi → MQTT → subscriber

Signal Quality (Confirmed)

Derived on the server side:

Acceleration magnitude
mag = sqrt(x² + y² + z²)

Vibration proxy
vib = |mag − baseline|

•


  • Baseline = slow EMA to remove gravity and orientation

Observed behavior:

• Machine OFF → low, stable vib

• Machine RUNNING → sustained elevated vib

• Impacts / tool contact → sharp spikes

The signal clearly separates machine states.

Visualization (Working)

• Live plots of the last ~10 seconds

• Shows:

  • Raw acceleration magnitude

  • Vibration proxy

• Confirms real-time response to machine behavior

Key Issues Found and Resolved

• Device only ran when Arduino IDE opened

  • Root cause: while (!Serial) blocking boot

  • Fixed by removing serial dependency

• Sensor failures when mounted on machine

  • Root causes: power quality, timing, EMI sensitivity

  • Fixed with:

    • Wall power

    • I2C speed reduction

    • Retry-based sensor initialization

Current State

✅ Hardware stable
✅ Telemetry streaming reliably
✅ Signal quality sufficient for classification
✅ End-to-end data path proven
⏸️ No ML or state inference yet

Next Phase (Planned)

Machine-learning–based state inference

• Start with OFF vs RUNNING

• Use vibration features:

  • RMS

  • Variance

  • Frequency energy

• Decide inference location:

  • Server-side first

  • Edge later if needed

Publish results to:
workshop/lathe/state
